Aero-naut Delta 24 TRIGON EDF Kit
Aero-naut Delta 24 TRIGON EDF Kit
Aero-Naut
Regular price
£169.99
Regular price
Sale price
£169.99
Unit price
/
per
Taxes included.
Couldn't load pickup availability
Product information "Delta 24 TRIGON"
Delta 24 Trigon is a sleek and compact impeller model in conventional timber construction. The model is designed for the Mini-Fan evo from WeMoTec, an impeller with a diameter of 69 mm. With a suitable choice of drive, a thrust/weight ratio of almost 1:1 is possible.
An ideal drive for the Delta 24 Trigon is the Mini-Fan evo / HET 2W22 impeller set in conjunction with the MF D8 nozzle, which is matched to the drive. The drive delivers 11.8 N thrust to 4S-LiPo, while the current remains below 50 A.
Batteries with a capacity of 3,000 mAh promise a good combination of low take-off weight and long flight time. An addition of ballast to adjust the center of gravity is not necessary with this design.
The assembly is carried out on the slipway typical of aero-naut models, and construction is quick and uncomplicated. The detailed assembly instructions show and describe the individual construction steps and leave no question unanswered. Nevertheless, experience with fast RC models is required to build and especially fly the model.
Specifications:
| Span | approx. 930 mm |
| Hull length | approx. 810 mm |
| Weight | from approx. 1,400 g |
| Area | approx. 29 dm² |
| Wing loading | from approx. 48 g/dm² |
| RC Functions | Height/Transverse (Mixed) Engine |
Product Ref: 131700
EAN: 4012230092621
| Claim flying: | Expert |
|---|---|
| Model version: | Wooden kit |
| Difficulty level: | 4 / 5 (Pro) |
